| _ | _ | № | Number | Qty | Name | Options |
|---|---|---|---|---|---|---|
| |$0 | 707000K041 | 1 | Cylinder Assembly | SN: 18687-UP | ||
| |$1 | 707000K040 | 1 | Cylinder Assembly | SN: 18401-18686 | ||
| 1 | 7071180F11 | 1 | Cylinder | SN: 18401-UP | ||
| 2 | 0289611009 | 2 | O-ring, (Kit : K08, K09) | SN: 18401-UP | ||
| 3 | 7215845420 | 1 | Rod, Piston | SN: 18401-UP | ||
| 4 | 7077645780 | 1 | Bushing | SN: 18401-UP | ||
| 5 | 20U7042530 | 2 | Seal, Dust, (Kit : K08, K09) | SN: 18401-UP | ||
| 6 | 0702000000 | 1 | Fitting, Grease | SN: 18401-UP | ||
| 7 | 7077640690 | 1 | Bushing | SN: 18401-UP | ||
| 8 | 0714500040 | 2 | Seal, Dust, (Kit : K08, K09) | SN: 18401-UP | ||
| 9 | 7077170860 | 1 | Plunger | SN: 18401-UP | ||
| 10 | 7072980891 | 1 | Head, Cylinder | SN: 18401-UP | ||
| 11 | 7075645740 | 1 | Seal, Dust, (Kit : K09) | SN: 18586-UP | ||
| 11 | 1126315370 | 1 | Seal, Dust, (Kit : K08) | SN: 18401-18585 | ||
| 12 | 0717912057 | 1 | Ring, Snap | SN: 18401-UP | ||
| 13 | 7075145210 | 1 | Packing, Rod, (Kit : K08, K09) | SN: 18401-UP | ||
| 14 | 0700012080 | 1 | O-ring, (Kit : K08, K09) | SN: 18401-UP | ||
| 15 | 0700012075 | 2 | O-ring, (Kit : K09) | SN: 18687-UP | ||
| 15 | 7073552750 | 1 | Ring, Back-up, (Kit : K08) | SN: 18401-18686 | ||
| 16 | 0714602076 | 3 | Ring, Back-up, (Kit : K09) | SN: 18687-UP | ||
| 16 | 0700012075 | 2 | O-ring, (Kit : K08) | SN: 18401-18686 | ||
| 17 | 0714602076 | 2 | Ring, Back-up, (Kit : K08, K09) | SN: 18401-UP | ||
| 18 | 7073680230 | 1 | Piston | SN: 18401-UP | ||
| 19 | 7074480180 | 1 | Ring, Piston, (Kit : K08, K09) | SN: 18401-UP | ||
| 20 | 0715600810 | 1 | Ring, Wear, (Kit : K08, K09) | SN: 18401-UP | ||
| 21 | 7076730030 | 1 | Nut | SN: 18401-UP |
